From this point use the standard method to launch a Quick Connection: Tap Sidebar button (top right), then Tap QuickConnect -> Serial, and then select "Airconsole-TS. The Get Console Quick Connect dialog will report any detected Airconsole with multiple ports as "Airconsole TS". Get Console will auto-detect the Airconsole device. After connecting iPad/iPhone to the Airconsole-XX WIFI network, Launch the Get Console app. Get Console v2.1 and later supports Airconsole with 1 or more 4 port cable kits connected. Press Connect after selecting a new port. When Airconsole detects 1 or more 4 port cable kits are attached, then the dropdown port selector on right hand side of terminal will allow for selection of ports 2 onwards. This simple terminal is based on Websockets, so requires a relatively modern web browser - such as IE10+, Safari 7+, Firefox 36, Chrome 40+įor simple and rapid terminal work we recommend using this built in web console as it is fast and convenient and can be used from any Mac, PC or iOS Device without installing any additional client terminal application.
USB TO RS232 CABLE SOLUTION FOR MAC OS SERIAL
Like the single port Airconsole, the serial device connected can be accessed via Airconsole via 5 different ways:Īfter connecting to Airconsole via Wifi or Wired IP method (see Airconsole User Manual), Access the web console via the Airconsole’s built in Web interface. We recommend for extended or permanent installation of Airconsole with 8 or more serial ports to use Airconsole TS adaptor. Note on multiple 4 port cable kits connected together: - current Airconsole Standard/Pro/XL can work with an 8 or 12 port cable configuration, however the charging rate of the Airconsole Std/Pro/XL battery while attached is lower than the power drain required to operate 2 or more 4 port cable kits, so after approximately 2 hours of use the Airconsole battery will fully drain and the connection will fail. Ports 2,3,4 (and later if multiple kits are connected) are only accessible via IP (Wired or WIFI connection) or USB (Direct connection) Note on Bluetooth Operation: Bluetooth allows only access to the first Serial port in the 4 cable kit.
USB TO RS232 CABLE SOLUTION FOR MAC OS DRIVERS
FTDI drivers should automatically download, however if do not are available here Requires Windows 7 or later (Not tested on Windows 10)
USB TO RS232 CABLE SOLUTION FOR MAC OS MAC OSX
(for Mac OSX COM port mapping over WIFI/Bluetooth LE) - AirconsoleConnect.pkg must be installed which creates 4 serial tty lines over IP connection to Airconsole - your Mac applications can then access these local TTY lines as if the serial cables were directly connected to your Mac). Your Windows application can access these COM ports as if the serial cable was directly connected to Windows PC.
USB TO RS232 CABLE SOLUTION FOR MAC OS DRIVER
(for Windows COM port mapping over WIFI) - AirconsoleConnect.exe driver or HWGroup drivers must be installed - this driver will create 4 COM ports over an IP connection to Airconsole. However if Wireless/Wired operation is required then:
If COM ports are required by Windows / Mac application the best solution is to connect the 4 port cable directly to the Mac/PC via USB (see direct use below). If using the 4 port cable kit connected to an Airconsole, and a COM port is needed on Windows / OS X then additional drivers are required. Get Console on iOS, Serialbot on Android, PuTTY on Windows, Macwise on Mac) inside a rack as a terminal device server) is desired. Airconsole Mini or TS are required where more than one 4 port cable kit is connected to a single Airconsole and extended / permanent installation (i.e.
All Airconsoles including version 1.0 and 2.0, Standard, Pro or XL models support a single 4 port cable kit.
USB TO RS232 CABLE SOLUTION FOR MAC OS FOR FREE
Firmware can be downloaded for free from this site. requires Airconsole firmware version 2.60 or later. The Kit consists of the following contentsġ x Cable unit with 4 RJ45 Serial cables (1.8m each), 1 USB male connector and 1 USB female port.ġ x Bluetooth 2.1/4.0 Radio adaptor (installed in the USB female port)ġ x Industrial Velcro self adhesive patch for mounting When connecting up additional cable kits, the units slide together firmly to create a single physical unit. The USB female port can be used to connect either an additional 4 port cable kit or the included Bluetooth radio module. The cable unit enclosure features an additional USB female port, a slide rail on one side and slide socket on the other. The kit is designed to be attached via USB to an Airconsole for Wifi/Wired/Bluetooth use or attached by USB directly to a PC or Mac for allowing concurrent access to 4 separate serial connections via a single Airconsole adaptor. Modified on: Fri, 17 Apr, 2015 at 11:40 AMĪirconsole 4 Port Cable Kit ( Partcode USB-TS-KIT-4) is a USB to 4 port RS232 serial cable. Solution home General Documentation Airconsole 4 Port USB Serial Cable
